Prism 3D Effect Projection Lens for all ECO Spot Models that use E-Size Gobos - 36º Wide

Description

Important: The max. Gobo Image Diameter for this lens is 25mm.
It works best with dedicated circular gobo artworks.
For use with the ECO Spot projector models LED10, A25, C25, B40, C40, B60.

This lens splits the image up into three sub images that. The resulting projection has the equivalent of a 36 degree spread. It creates an overlay 3-dimensional effect to add motion and depth to your projection.
At a distance of 12 ft., the prism lens will produce an image of approximately 8 ft.
At 24 ft., you will get an image diameter of 16 ft.

Because of the wide image spread, the lens is meant to be operated in less bright environments.

Specificatons

Focal Length:	28mm
Lens Angle E-size:	36º with E-size gobos
Lens Angle D-size:	36º with D-size gobos and max. ID of 25mm
Thread diameter:	39mm (1.5in)
